Measurement range: DO: 0-20 mg/L, 0-20 ppm; Temperature: 0-45°C
Measurement accuracy: DO: ±3% of the measured value; Temperature: ±0.5°C
Pressure range: ≤0.3Mpa
Calibration: Air automated calibration, sample calibration
Main material: Body: SUS316L + PVC(fresh water), Titanium alloy (marine); O-ring : fluorine rubber; Cable : PVC
Power supply: AC:100-240VAC (50/60HZ)DC: 9~36VDC
Output: 2-way 4-20mA
Relay: Setting three-way relays, programmed response parameter and response value.
Communication protocol: MODBUS RS485
Storage temperature: (-15) - 65°C
Measuring temperature: 0-45°C
Dimensions Sensor: Dia 55mm*L 342mm
Transmitter: 145*125*162mm (L*W*H)
Weight Sensor: 1.85KG;
Transmitter: 1.35KG
Protective rate: Sensor: IP68/NEMA6P; Transmitter: IP65/ NEMA4X
Cable length: Standard: 10m, the maximum may be extended to 100m
