CAMERA
Image Sensor -- 1/2.8” Progressive Scan CMOS Sensor
Video System -- PAL / NTSC
Lens -- 2.8-12mm
Resolution -- 2MP
Signal System -- AHD (Analog High Definition)
Eective Pixels -- 1920x1080
Weatherproof -- IP66
Day/Night Switch Mode -- IR-CUT (double filter switch)
LEDs -- 42pcs
White Balance -- Auto
Back Light Compensation -- Auto
Min.lllumination Color: 0.1 Lux (F1.2, AGC ON), 0 Lux (IR LED ON at night) B/W: 0.01 Lux (F1.2, AGC ON), 0 Lux (IR LED ON at night)
Lens Port -- Auto
S/N Ratio -- More than 48dB (AGC OFF)
Power Consumption -- Max 8.0W (day/night time)
Synchronization -- Internal Sync
Video Output -- 1.0Vp-p, 75Ω (BNC Composite Output)
I/O Port -- Video (BNC Interface) / Power (DC Interface)
GENERAL
Electronic Shutter -- 1/50 ( 1/60 ) ~1/10,000 Sec
Operating Temperature -- 10 – 45oC
Material -- Metal
Power Supply -- DC12V -+ 10% / 650mA
IR Range -- 40 meter
Transmission Distance -- Upto 500m (Coaxial Video Cable)
Working Humidity -- 0% - 90%
Weight -- 1.2KG
