CAMERA
Image Sensor -- 1/2.7” Progressive Scan CMOS Sensor
Video System -- PAL / NTSC
Lens -- 3.6mm
Resolution -- 2MP
Signal System -- AHD /TVI/CVI(1080P),CVBS
Eective Pixels -- 1920x1080
Weatherproof -- IP66
Day/Night Switch Mode -- IR-CUT (double filter switch)
LEDs -- 24pcs
White Balance -- Auto
Back Light Compensation -- Auto
Min.lllumination Color: 0.1 Lux (F1.2, AGC ON), 0 Lux (IR LED ON at night) B/W: 0.01 Lux (F1.2, AGC ON), 0 Lux (IR LED ON at night)
Lens Port -- M12/CS
S/N Ratio -- More than 48dB (AGC OFF)
Power Consumption -- Max 8.0W (day/night time)
Synchronization -- Internal Sync
Video Output -- 1.0Vp-p, 75Ω (BNC Composite Output)
I/O Port -- Video (BNC Interface) / Power (DC Interface)
OSD -- YES
GENERAL
Electronic Shutter -- 1/50 ( 1/60 ) ~1/10,000 Sec
Operating Temperature -- 10 – 60oC
Material -- Metal
Power Supply -- DC12V -+ 10% / 650mA
IR Range -- 20 meter
Transmission Distance -- Upto 500m (Coaxial Video Cable)
Working Humidity -- 0% - 90%
Weight -- 0.4 KG
