CAMERA
Image Sensor -- 2MP, 1/2.8" Image sensor
Operating System -- Embedded Linux
Signal System -- PAL/NTSC
Min. Illumination Color: 0.05 Lux @(F1.2, AGC ON) B/W: 0.01Lux @(F1.2, AGC ON); 0 Lux with IR
Shutter time -- 1/25s to 1/10000s
Lens -- 3.6 mm
Angle of View -- 80°
Lens Mount -- φ12
Adjustment Range -- PAN; 0° - 355°, Tilt: 0° - 75°, Rotation: 0-355°
Day & Night -- IR Cut filter with Auto Switch
Wide Dynamic Range -- D-WDR
Digital Noise Reduction -- 3D DNR
Auto Iris -- Auto
COMPRESSION STANDARD
Video Compression -- H.264
Video bit rate -- 32Kbps-8Mbps
Max. Image Resolution -- 1920x1080
Dual Stream Mainstream:1080P(1920x1080), Substream:D1(704x576)
Image Settings -- Brightness, Saturation, Contrast,Flip Mode Adjustable by Client Software or Web Browser
Corridor -- Yes,16:9 to 9:16 Only for 1080P
NETWORK
Network Storage -- FTP
Alarm Trigger -- Motion Detection/IP Conflict/MAC Conflict/Port Alarm/Mask Alarm
User Permission -- 4 Level/8 User
Remote Connections -- 4 Users
Protocols -- TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x
System Compatibility -- ONVIF (Profile S), SDK
INTERFACE
Communication Interface -- 1 RJ45 10M / 100M Ethernet interface
Alarm -- NA
GENERAL
Power supply -- 12 VDC ± 10%, PoE (802.3af)
Power Consumption -- 5 W (LED OFF)/ 11 W(LED ON)
Circuit Protection -- TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V)
Weather Proof -- IP66
IR Range -- 20M
IR leds -- 24PCS IR LEDs
Weight -- 1KG
