10 Channel
NVR

10 Channel

NVR recorders are surveillance camera recorders for IP surveillance cameras that use a RJ45 port to transmit video, data, and power. The 10 channel NVRs below support recording of up to 10 network cameras simultaneously, with resolutions up to 5 megapixels.

S+265 Compression

Up to 5MP Resolution Recording

Support 10-ch Intelligent Analysis Process

Smart Search & Recording

Support ANR Function

Cloud upgrade,IPC Cloud upgrade

Plug in free

1× HDMI, 1× VGA, Same Video Source, Max Resolution 1080p

1 SATA(Up to 10TB), 2× USB

UI V3.0,Support free dragging of UI navigation bar

H.265 10 Channel 1HDD Network Video Recorder

Video/Audio Input
Video Input -- 10-ch
Audio Input N/A

Network
Incoming Bandwidth -- 40Mbps
Outgoing Bandwidth -- 40Mbps
Mobile Software -- P2P/IP for IOS&Android (App Name: Easylive)
Internet Protocol -- TCP/UDP/HTTP/MULTICAST/UPnP/DHCP/DDNS/NTP/RTSP/SADP etc
ANR -- Yes
Remote Connection -- 64
Browser -- Support all browsers, including IE, Safari, Chrome, Edge. (H.265 only supports configuration in non-IE kernel browsers)
Advanced -- Remaining Bandwidth Display

Video/Audio Output
HDMI Output -- 1-ch, Resolution 1920×1080,1280×720,1440×900, 1366×768, 1280×800,1024×768,800×600
VGA Output -- 1-ch, Resolution 1920×1080, 1280×720, 1440×900, 1366×768, 1280×800, 1024×768, 800×600 Adjustable Output mode, Self-adaptive Resolution
Audio Output -- N/A
Recording Resolution -- 5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback -- 2-ch 1080P/4-ch 720P
Display Split -- 1/3/4/6

Hard Disk
SATA 1 SATA for 1 HDD
Capacity Up to 10TB Capacity for Each HDD (0~45°C)

Advance
Video Analytics(VCA) -- Camera VCA Function, including Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Loitering/Running/Parking/Face Detection/Crowd/On duty Detection/Video Abnormal Detection/Audio Abnormal Detection/Video defocus diagnosis/Video scene transformation diagnosis
I-Frame Record -- Yes
Plug and Play -- N/A
Image Flip -- Yes, Only for Avazonic Cameras
Corridor Mode -- Yes, Only for Avazonic Cameras
Smart Search -- Quickly Search Target VCA Videos , Only for Tiandy Cameras
Trigger Recording -- Manual/Timing/Motion Detection/Port Alarm/ VCA Alarm/Video Lost
Alarm Recording -- Pre Alarm Default 10s ( 5/10/15/60s Optional) , Post Alarm Default 10s (10/15/30/60/600s Optional ).
Smart Recording -- Set Recording Bit Rate for Dierent Time
One Key Control -- Recording,one key add
Records Format -- SDV, MP4
Records Encryption -- Yes
Records Tag -- Yes
Onvif -- Onvif(Profile S)

General
Consumption (withoutHDD) -- ≤ 10W
Power Supply -- DC12V 3.33A
Working Temperature -- -10 oC ~ +55 oC (+14 oF~ + 131 oF)
Working Humidity -- 10 % ~ 90 %
Chassis -- 1U
Dimensions -- 45mm×255mm×231mm
Weight -- 0.8KG (without HDD)
